7205T1CWCBI
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Toggle Switches
Description
Switch Toggle Mom OFF Mom DPDT Round Lever PC Pins 20VAC 20VDC 0.4VA PC Mount with Threads
PDF
/
Inventory: 4518
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Max Operating Temperature 85°C
Min Operating Temperature -30°C
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Straight
Ingress Protection IP67 - Dust Tight, Waterproof
Depth 11.81mm
Termination Style PC Pin
Voltage - Rated AC 20V
Actuator Type Standard Round
Circuit DPDT
Switch Function Mom-Off-Mom
Panel Cutout Dimensions Circular - 11.91mm Dia
Max Voltage Rating (AC) 20V
Electrical Life 40,000 Cycles
Throw Configuration DP, DPDT
Illumination Non-Illuminated
Max Voltage Rating (DC) 20V
Illumination Type Illuminated, Non-Illuminated
Bushing Thread 15/32-32
Termination PC Pin
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Epoxy Potted
Series 7000
Published 2012
Packaging Bulk
Operating Temperature -30°C~85°C
Dimensions
Length 12.7mm
Actuator Length 12.37mm
Compliance
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP67, Waterproof
Physical
Actuator Material Brass, Chrome Plated
Housing Material Stainless Steel
Mounting Type Panel Mount
Mount Panel
Contact Plating Gold
Contact Material Gold
Supply Chain
Factory Lead Time 14 Weeks
