EG2201
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Slide Switches
Description
SWITCH SLIDE DPDT 300MA 30V
PDF
/
Buying Options
Total Price: USD $0.92
Unit Price: USD $0.9152
≥1 USD $0.9152
≥10 USD $0.88088
≥100 USD $0.65017
≥500 USD $0.558738
≥1000 USD $0.474082
≥3000 USD $0.44022
Inventory: 1195
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Contact Material Copper Alloy
Mount Through Hole
Mounting Type Through Hole
Technical
Operating Temperature -20°C~70°C
Packaging Bulk
Published 2004
Series EG
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination PC Pin
ECCN Code EAR99
Number of Positions 2
HTS Code 8536.50.90.50
Voltage - Rated DC 30V
Current Rating (Amps) 300mA DC
Orientation Vertical
Current Rating 300mA
Contact Finish Silver
Termination Style PC Pin
Voltage - Rated AC 30V
Body Length or Diameter 16mm
Body Breadth 6.5 mm
Actuator Type Standard
Circuit DPDT
Switch Function On-On
Contact Style Non-Shorting
Electrical Life 10000 cycles
Switch Type SLIDE SWITCH
Contact Current Rating 200mA
Operating Force 200gf
Contact Timing Non-Shorting (BBM)
Switch Travel 4.00mm
Dimensions
Body Height 8mm
Actuator Length 3.00mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
