1825097-9
RoHS
/
Package /
Category Switches / Pushbutton Switches
Description
Switch Push Button ON Mom SPDT Round Plunger 20VAC 20VDC 0.4VA Momentary Contact PC Pins Thru-Hole Loose Piece
PDF
/
Inventory: 7002
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Actuator Length 3.48mm
Body Height 8.84mm
Length 8.13mm
Technical
Operating Force-Max 3.92 N
Contact (DC) Max Rating R Load .02A@20VDC
Contact (AC) Max Rating R Load .02A@20VAC
Contact Current(AC)-Max 0.02A
Max Voltage Rating (DC) 20V
Throw Configuration SPDT
Electrical Life 100000 cycles
Max Voltage Rating (AC) 20V
ELV Compliant
Sealing EPOXY TERMINAL SEALED
Contact Current(DC)-Max 0.02A
Contact Resistance 20mOhm
Switch Function On-Mom
Body Breadth 5.23 mm
Voltage - Rated AC 20V
Depth 5.99mm
Orientation Straight
Packing Method BULK
Voltage - Rated DC 20V
HTS Code 8536.50.90.31
Min Operating Temperature -30°C
Max Operating Temperature 65°C
Terminal Finish Gold (Au)
Type Switch
ECCN Code EAR99
Termination PC Pins
Pbfree Code yes
JESD-609 Code e4
Physical
Actuator Material Polyamide
Housing Material Nylon
Mount Through Hole
Contact Plating Gold, Nickel
Contact Material Brass
