207613-1

TE Connectivity
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Receptacles, Female Sockets
Description CONN HEADER SOCKT 10POS VERT TIN
PDF
/
Inventory: 4152
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 20 Weeks

Physical

Contact Material Bronze
Contact Plating Lead, Tin
Mount Through Hole
Shell Material POLYAMIDE
Housing Material Nylon
PCB Mounting Orientation Vertical

Technical

Packaging Bulk
Published 2005
Number of Terminations 10
Termination Solder
ECCN Code EAR99
Connector Type Header, Plug, Socket
Max Operating Temperature 130°C
Min Operating Temperature -55°C
Color Red
Number of Rows 1
Voltage - Rated 600V
Additional Feature METRIMATE
HTS Code 8536.69.40.30
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 5.0038mm
Total Number of Contacts 10
Depth 11mm
Current Rating 14A
Number of Conductors ONE
Reliability COMMERCIAL
Approval Agency UL
Number Of PCB Rows 1
Body Breadth 0.433 inch
Contact Gender Female
UL Flammability Code 94V-0
Empty Shell NO
Contact Style RND PIN-SKT
ELV Non-Compliant
Max Voltage Rating (AC) 600V
Polarization Key POLARIZED HOUSING
Number of Ports 1
Max Voltage Rating (DC) 600.6kV
Contact Rating (Current) 7.5A
VDE Tested Yes

Dimensions

Height 19.51mm
Length 71.6mm
Width 11mm
Length - Tail 4.72mm
PCB Thickness 1.6002mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
