0026486248

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description 156 KK BKWY HDR POLZ SQP 24POS
PDF
/
Inventory: 5775
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant
Material Flammability Rating UL94 V-0

Dimensions

Contact Finish Thickness - Post 60.0μin 1.52μm
Contact Finish Thickness - Mating 60.0μin 1.52μm

Technical

Overall Contact Length 0.750 19.05mm
Contact Length - Mating 0.497 12.62mm
Contact Finish - Post Tin
Number of Contacts 24
Lead Pitch 3.96mm
Shrouding Shrouded - 1 Wall
Contact Length - Post 0.125 3.18mm
Insulation Color Black
Pitch - Mating 0.156 3.96mm
Number of Positions Loaded All
Style Board to Board or Cable
Insulation Height 0.360 9.14mm
Pitch 3.9624mm
Contact Type Male Pin
Contact Finish - Mating Tin
Fastening Type Push-Pull
Gender Male
Number of Rows 1
Applications Automotive, General Purpose, Industrial, Medical, Telecommunications
Color Black
Number of Positions 24
Connector Type Header, Breakaway
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series KK 41681
Packaging Bulk

Physical

Insulation Material Polyester, Glass Filled
Contact Shape Square
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Contact Material Brass

Supply Chain

Factory Lead Time 16 Weeks
