TL431ACDE4
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Voltage Reference
Description
R-PDSO-G8 Tube NICKEL PALLADIUM GOLD Shunt voltage reference device 600muA 36V 143.143ppm/C 1.75mm
PDF
/
Buying Options
Total Price: USD $0.14
Unit Price: USD $0.1408
≥1 USD $0.1408
Inventory: 1400
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Packaging Tube
Tolerance ±1%
JESD-609 Code e4
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish NICKEL PALLADIUM GOLD
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
JESD-30 Code R-PDSO-G8
Number of Outputs 1
Operating Temperature (Max) 70°C
Output Voltage 2.495V
Output Type Adjustable
Supply Voltage-Max (Vsup) 36V
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 2.495V
Trim/Adjustable Output YES
Analog IC - Other Type TWO TERMINAL VOLTAGE REFERENCE
Current - Output 100mA
Voltage - Output (Min/Fixed) 2.495V
Reference Type Shunt
Voltage - Output (Max) 36V
Output Voltage-Min 2.47V
Temp Coef of Voltage-Max 143.143 ppm/°C
Current - Cathode 600μA
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
