784770470
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PDA Nonstandard 0.472Lx0.472W 12.00mmx12.00mm 47muH
PDF
/
Buying Options
Total Price: USD $2.42
Unit Price: USD $2.421591
≥1 USD $2.421591
≥10 USD $2.284517
≥100 USD $2.155206
≥500 USD $2.03322
≥1000 USD $1.918128
Inventory: 5671
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
Dimensions
Width 11.9888mm
Length 11.9888mm
Height Seated (Max) 0.327 8.30mm
Technical
Current - Saturation 3.4A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 7.9MHz
DC Resistance (DCR) 71mOhm Max
Test Frequency 100kHz
Inductance 47μH
Current Rating 3.1A
Shielding Shielded
Current Rating (Amps) 3.1A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.472Lx0.472W 12.00mmx12.00mm
Series WE-PDA
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Nickel Zinc Ferrite (NiZn)
Supplier Device Package 1280
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 22 Weeks
