7447715220
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD Nonstandard 0.472Lx0.472W 12.00mmx12.00mm 22muH
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.34235
≥1 USD $1.34235
≥10 USD $1.102
≥100 USD $1.0678
≥500 USD $1.03265
≥1000 USD $0.99845
Inventory: 38892
Minimum: 1
-
+
Technical Details
Technical
Current Rating (Amps) 2.9A
Shielding Shielded
Depth 12mm
Current Rating 2.9A
Inductance 22μH
Test Frequency 1kHz
DC Resistance (DCR) 65mOhm Max
Max DC Current 2.9A
Frequency - Self Resonant 15.5MHz
Inductance Frequency - Test 1kHz
Current - Saturation 3.1A
Inductance Tolerance 20%
RMS Current (Irms) 2.9A
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 65mOhm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.472Lx0.472W 12.00mmx12.00mm
Series WE-PD
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Dimensions
Height 4.5mm
Height Seated (Max) 0.177 4.50mm
Length 12mm
Width 12mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
