P1330-223G
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Active WRAPAROUND Fixed Inductor -55C~125C 1kHz 384mOhm Max 22muH
PDF
/
Inventory: 9182
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.145 3.68mm
Height 3.68mm
Technical
Case/Size Code 3111
Current - Saturation 348mA
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 694mA
DC Resistance (DCR) 384mOhm Max
Test Frequency 1kHz
Inductance 22μH
Current Rating 694mA
Depth 3.18mm
Number of Functions 1
Shielding NO
Packing Method TR, 7 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code no
JESD-609 Code e0
Tolerance ±2%
Size / Dimension 0.325Lx0.125W 8.26mmx3.18mm
Series P1330
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
