7447714681

Würth Elektronik
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description WE-PD Performance Nonstandard 0.394Lx0.394W 10.00mmx10.00mm 680muH
PDF
/
Buying Options
Total Price: USD $1.97
Unit Price: USD $1.968087
≥1 USD $1.968087
≥10 USD $1.856691
≥100 USD $1.751588
≥500 USD $1.652451
≥1000 USD $1.558905
Inventory: 1671
Minimum: 1
-
+

Technical Details

Compliance

Ratings AEC-Q200
RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 10mm
Length 10mm
Height Seated (Max) 0.197 5.00mm
Height 5mm

Technical

Series Resistance 1.22Ohm
RMS Current (Irms) 510mA
Inductance Tolerance 20%
Current - Saturation 710mA
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 2.05MHz
Max DC Current 510mA
DC Resistance (DCR) 1.22Ohm Max
Test Frequency 100kHz
Inductance 680μH
Current Rating 510mA
Depth 10mm
Shielding Shielded
Current Rating (Amps) 510mA
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 1.22Ohm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.394Lx0.394W 10.00mmx10.00mm
Series WE-PD Performance
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C

Physical

Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Factory Lead Time 12 Weeks
