B82475A1684K000
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Inductor Power Wirewound 680uH 10% 100KHz Ferrite 280mA 2.25Ohm DCR Automotive Blister T/R
PDF
/
Inventory: 6219
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.228 5.80mm
Technical
Current - Saturation 300mA
Inductance Frequency - Test 100kHz
DC Resistance (DCR) 2.25Ohm Max
Inductance 680μH
Shielding Unshielded
Current Rating (Amps) 280mA
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±10%
Size / Dimension 0.409Lx0.370W 10.40mmx9.40mm
Series B82475A1
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
