7447713100
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-PD Performance Nonstandard 0.394Lx0.394W 10.00mmx10.00mm 10muH
PDF
/
Buying Options
Total Price: USD $17.43
Unit Price: USD $17.4268
≥1 USD $17.4268
≥10 USD $14.2994
≥100 USD $13.85195
≥500 USD $13.40545
≥1000 USD $12.95895
Inventory: 1106
Minimum: 1
-
+
Technical Details
Compliance
Ratings AEC-Q200
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 0.118 3.00mm
Height 3mm
Technical
Series Resistance 62mOhm
RMS Current (Irms) 2.6A
Inductance Tolerance 20%
Current - Saturation 4.1A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 25MHz
Max DC Current 2.6A
DC Resistance (DCR) 62mOhm Max
Test Frequency 100kHz
Inductance 10μH
Current Rating 2.6A
Depth 10mm
Shielding Shielded
Current Rating (Amps) 2.6A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 62mOhm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.394Lx0.394W 10.00mmx10.00mm
Series WE-PD Performance
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
