744373965330
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 33UH 4.7A 58 MOHM SMD
PDF
/
Buying Options
Total Price: USD $2.23
Unit Price: USD $2.232551
≥1 USD $2.232551
≥10 USD $2.106182
≥100 USD $1.986963
≥500 USD $1.874486
≥1000 USD $1.768387
Inventory: 1242
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 15 Weeks
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Supplier Device Package 1365
Material - Core Iron Powder
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-LHMI
Size / Dimension 0.551Lx0.504W 14.00mmx12.80mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Molded
Current Rating (Amps) 4.7A
Shielding Shielded
Inductance 33μH
DC Resistance (DCR) 58mOhm Max
Frequency - Self Resonant 4.4MHz
Inductance Frequency - Test 100kHz
Current - Saturation 10.1A
Dimensions
Height Seated (Max) 0.256 6.50mm
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
