23S330C
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
2300 Nonstandard 0.244Lx0.220W 6.20mmx5.60mm 33muH
PDF
/
Buying Options
Total Price: USD $0.5
Unit Price: USD $0.50499
≥1 USD $0.50499
≥10 USD $0.47641
≥100 USD $0.44944
≥500 USD $0.424
≥1000 USD $0.4
≥3000 USD $0.37736
Inventory: 2902
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape WRAPAROUND
Number of Pins 2
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 2300
Size / Dimension 0.244Lx0.220W 6.20mmx5.60mm
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Shielding YES
Number of Functions 1
Depth 5.6mm
Current Rating 650mA
Inductance 33μH
Test Frequency 1kHz
DC Resistance (DCR) 241mOhm Max
Max DC Current 650mA
Terminal Placement DUAL ENDED
Dimensions
Height 3.2mm
Height Seated (Max) 0.126 3.20mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
