744306025
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-HCM Nonstandard 0.413Lx0.406W 10.50mmx10.30mm 250nH
PDF
/
Buying Options
Total Price: USD $1.34
Unit Price: USD $1.338748
≥1 USD $1.338748
≥10 USD $1.262967
≥100 USD $1.191487
≥500 USD $1.124042
≥1000 USD $1.060413
Inventory: 1101
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Manganese Zinc Ferrite (MnZn)
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Series WE-HCM
Size / Dimension 0.413Lx0.406W 10.50mmx10.30mm
Tolerance ±20%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Current Rating (Amps) 25A
Shielding Shielded
Current Rating 26A
Inductance 250nH
Test Frequency 100kHz
DC Resistance (DCR) 0.26mOhm
Max DC Current 26A
Frequency - Self Resonant 400MHz
Inductance Frequency - Test 100kHz
Current - Saturation 32A
Inductance Tolerance 20%
RMS Current (Irms) 26A
Dimensions
Height 4.9784mm
Height Seated (Max) 0.217 5.50mm
Length 10.4902mm
Width 10.287mm
Compliance
REACH SVHC Unknown
RoHS Status ROHS3 Compliant
Lead Free Lead Free
