744065100
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
WE-TPC Nonstandard 0.394Lx0.394W 10.00mmx10.00mm 10muH
PDF
/
Buying Options
Total Price: USD $0.6
Unit Price: USD $0.6042
≥1 USD $0.6042
≥10 USD $0.4959
≥100 USD $0.47975
≥500 USD $0.46455
≥1000 USD $0.44935
Inventory: 1078
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC Unknown
Dimensions
Width 10mm
Length 10mm
Height Seated (Max) 0.122 3.10mm
Height 2.8mm
Technical
RMS Current (Irms) 3A
Inductance Tolerance 30%
Current - Saturation 2.5A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 25MHz
Max DC Current 3A
DC Resistance (DCR) 53mOhm Max
Test Frequency 100kHz
Inductance 10μH
Current Rating 3A
Depth 10mm
Shielding Shielded
Current Rating (Amps) 3A
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 45mOhm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±30%
Size / Dimension 0.394Lx0.394W 10.00mmx10.00mm
Series WE-TPC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Weight 880.989781mg
Number of Pins 2
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 14 Weeks
