74404086471
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
FIXED IND 470UH 650A 1.2OHM SMD
PDF
/
Buying Options
Total Price: USD $0.99
Unit Price: USD $0.989232
≥1 USD $0.989232
≥10 USD $0.933234
≥100 USD $0.88041
≥500 USD $0.830576
≥1000 USD $0.783565
Inventory: 1270
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Seated (Max) 0.256 6.50mm
Technical
Inductance Tolerance 20%
Current - Saturation 1.08A
Inductance Frequency - Test 100kHz
Frequency - Self Resonant 1.8MHz
DC Resistance (DCR) 1.2Ohm
Inductance 470μH
Shielding Shielded
Current Rating (Amps) 650mA
Type Wirewound
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.315Lx0.315W 8.00mmx8.00mm
Series WE-LQS
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Supplier Device Package 8065
Package / Case Nonstandard
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 13 Weeks
