IHB3BV101K
RoHS
RoHS compliant
RoHS compliantPackage Radial, Vertical Cylinder
Category Inductors, Coils, Chokes / Fixed Inductors
Description
Fixed Inductors Radial 100uH 10%
PDF
/
Inventory: 4311
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial, Vertical Cylinder
Technical
Operating Temperature -55°C~130°C
Packaging Bulk
Series IHB
Size / Dimension 1.100Dia 27.94mm
Tolerance ±10%
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Radial
Type Wirewound
Max Operating Temperature 80°C
Min Operating Temperature -55°C
Current Rating (Amps) 6A
Shielding Unshielded
Lead Pitch 19.56mm
Inductance 100μH
Test Frequency 1kHz
DC Resistance (DCR) 34mOhm Max
Max DC Current 17A
Lead/Base Style Radial
Inductance Frequency - Test 1kHz
Dimensions
Height 21.34mm
Height Seated (Max) 0.840 21.34mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
