DU6629-2R2M

TE Connectivity
RoHS
/
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description GENERAL PURPOSE INDUCTOR Non-RoHS Compliant Contains Lead 8504.50.80.00 Fixed Inductor 85C 100kHz 70mOhm 2.2muH
PDF
/
Inventory: 7509
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Package / Case Nonstandard
Core Material AMORPHOUS MAGNETIC

Technical

Packaging Tape & Reel (TR)
Series DU6629
Tolerance 20%
ECCN Code EAR99
Max Operating Temperature 85°C
Min Operating Temperature -40°C
HTS Code 8504.50.80.00
Packing Method TR
Shielding Unshielded
Current Rating 2.4A
Inductance 2.2 μH
Test Frequency 100kHz
Inductor Type GENERAL PURPOSE INDUCTOR
Current - Saturation 2.3A
Case/Size Code 2618
DC Resistance (DCR) - Parallel 70mOhm
Inductance-Nom (L) 2.2 μH

Dimensions

Height Seated (Max) 2.921mm
Length 6.604mm
Width 4.4958mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
