LQH32CH2R2M33L
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
LQH32 Nonstandard 0.126Lx0.098W 3.20mmx2.50mm 2.2muH
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.2147
≥1 USD $0.2147
≥10 USD $0.1767
≥100 USD $0.171
≥500 USD $0.1653
≥1000 USD $0.16055
Inventory: 505
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 2 weeks ago)
Physical
Mounting Type Surface Mount
Package / Case Nonstandard
Surface Mount YES
Terminal Shape WRAPAROUND
Weight 59.987591mg
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series LQH32
Size / Dimension 0.126Lx0.098W 3.20mmx2.50mm
Tolerance ±20%
JESD-609 Code e2
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin/Copper (Sn/Cu)
HTS Code 8504.50.80.00
Current Rating (Amps) 790mA
Shielding Unshielded
Number of Functions 1
Depth 2.7mm
Reference Standard AEC-Q200
Inductance 2.2μH
Test Frequency 1MHz
DC Resistance (DCR) 97mOhm
Max DC Current 600mA
Frequency - Self Resonant 64MHz
Inductor Application RF INDUCTOR
Terminal Placement DUAL ENDED
Inductance Frequency - Test 1MHz
Special Feature DCR IS MEASURED AT 30% TOLERANCE
Dimensions
Height 2mm
Height Seated (Max) 0.087 2.20mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
