P0762.334NLT image
Favorite
P0762.334NLT image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description P0762NL Nonstandard 0.510Lx0.370W 12.95mmx9.40mm 330muH
PDF
/
Inventory: 9994
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Height Seated (Max) 0.118 3.00mm
Height 2.9972mm

Technical

Special Feature INDUCTANCE MEASURED WITH PEAK DC CURRENT
Case/Size Code 5137
Current - Saturation 400mA
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 400mA
DC Resistance (DCR) 2.7Ohm Max
Test Frequency 100kHz
Inductance 330μH
Current Rating 300mA
Depth 9.4mm
Number of Functions 1
Shielding NO
Packing Method TR
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.510Lx0.370W 12.95mmx9.40mm
Series P0762NL
Packaging Tape & Reel (TR)
Operating Temperature -40°C~130°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
