40470C
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
4000 Nonstandard 0.560Lx0.555W 14.22mmx14.10mm 47muH
PDF
/
Inventory: 7968
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Series 4000
Size / Dimension 0.560Lx0.555W 14.22mmx14.10mm
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Toroidal
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Shielding NO
Number of Functions 1
Depth 14.1mm
Current Rating 1.42A
Inductance 47μH
Test Frequency 10kHz
DC Resistance (DCR) 79mOhm Max
Max DC Current 1.42A
Inductor Application DC-DC CONVERTER
Terminal Placement DUAL ENDED
Dimensions
Height 8.76mm
Height Seated (Max) 0.345 8.76mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
