24S680C image
Favorite
24S680C image
Favorite
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description 2400 Nonstandard 0.303Lx0.280W 7.70mmx7.10mm 68muH
PDF
/
Inventory: 3824
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 10 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard

Technical

Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 2400
Size / Dimension 0.303Lx0.280W 7.70mmx7.10mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Composition Wirewound
Current Rating (Amps) 630mA
Shielding Shielded
Depth 7.1mm
Current Rating 630mA
Inductance 68μH
Test Frequency 1kHz
DC Resistance (DCR) 370mOhm Max
Max DC Current 630mA
Frequency - Self Resonant 8.09MHz
Inductance Frequency - Test 1kHz

Dimensions

Height 4.5mm
Height Seated (Max) 0.177 4.50mm
Length 7.6962mm
Width 7.1mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
