1229AS-H-220M=P3

Murata Electronics
RoHS
RoHS RoHS compliant
Package Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description Nonstandard 0.146Lx0.154W 3.70mmx3.90mm 22muH ±20%
PDF
/
Buying Options
Total Price: USD $0.63
Unit Price: USD $0.6336
≥1 USD $0.6336
≥10 USD $0.5412
≥100 USD $0.495968
≥500 USD $0.450912
≥1000 USD $0.401368
≥3000 USD $0.378787
Inventory: 1323
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height Seated (Max) 0.047 1.20mm

Technical

Rated Current-Max 0.53A
Current - Saturation 500mA
Inductance Frequency - Test 100kHz
Terminal Placement DUAL ENDED
DC Resistance (DCR) 672mOhm Max
Test Frequency 100kHz
Inductance 22μH
Current Rating 530mA
Number of Functions 1
Shielding YES
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.146Lx0.154W 3.70mmx3.90mm
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C

Physical

Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 13 Weeks
