SRU5028A-220Y
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SRU5028A Nonstandard 0.205Lx0.205W 5.20mmx5.20mm 22muH
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.837239
≥1 USD $0.837239
≥10 USD $0.789854
≥100 USD $0.745143
≥500 USD $0.702957
≥1000 USD $0.663168
Inventory: 1154
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2004
Series SRU5028A
Size / Dimension 0.205Lx0.205W 5.20mmx5.20mm
Tolerance ±30%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
HTS Code 8504.50.80.00
Shielding Shielded
Depth 5.4mm
Current Rating 950mA
Military Standard Not
Inductance 22μH
Test Frequency 100kHz
DC Resistance (DCR) 210mOhm Max
Max DC Current 950mA
Frequency - Self Resonant 18MHz
Q @ Freq 15 @ 2.52MHz
Current - Saturation 850mA
Inductance Tolerance 30%
RMS Current (Irms) 950mA
Dimensions
Height 2.8mm
Height Seated (Max) 0.118 3.00mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Ratings AEC-Q200
