SD3114-101-R
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SD3114 Nonstandard 0.122Lx0.122W 3.10mmx3.10mm 100muH
PDF
/
Buying Options
Total Price: USD $2.75
Unit Price: USD $2.7544
≥1 USD $2.7544
≥10 USD $2.3408
≥100 USD $2.157056
≥500 USD $1.927552
≥1000 USD $1.606264
≥3000 USD $1.560381
Inventory: 1177
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 3.0988mm
Length 3.0988mm
Height Seated (Max) 0.055 1.40mm
Height 1.4mm
Technical
Current - Saturation 252mA
Inductance Frequency - Test 100kHz
Max DC Current 252mA
DC Resistance (DCR) 3.3Ohm
Test Frequency 100kHz
Inductance 100μH
Current Rating 213mA
Shielding Shielded
Current Rating (Amps) 213mA
Composition Wirewound
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Resistance 3.3Ohm
Type Wirewound
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance ±20%
Size / Dimension 0.122Lx0.122W 3.10mmx3.10mm
Series SD3114
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Material - Core Ferrite
Weight 453.59237mg
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
