PM3316-101M-RC
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
PM3316 Nonstandard 0.500Lx0.394W 12.70mmx10.00mm 100muH
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.7656
≥1 USD $0.7656
≥10 USD $0.64592
≥100 USD $0.587136
≥500 USD $0.55176
≥1000 USD $0.457864
≥3000 USD $0.422646
Inventory: 12291
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Height Seated (Max) 0.209 5.30mm
Height 5mm
Technical
RMS Current (Irms) 1A
DC Current 1A
Inductance Tolerance 20%
Case/Size Code 5039
Q Factor 30
Current - Saturation 1.2A
Quality Factor-Min (at L-nom) 30
Q @ Freq 30 @ 50kHz
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 8MHz
Max DC Current 1A
DC Resistance (DCR) 330mOhm
Test Frequency 1kHz
Inductance 100μH
Military Standard Not
Current Rating 1.3A
Depth 10.2mm
Number of Functions 1
Shielding NO
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.500Lx0.394W 12.70mmx10.00mm
Series PM3316
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 2
Terminal Shape WRAPAROUND
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 16 Weeks
