78FR10M
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
78F Axial 0.110Diax0.280L 2.79mmx7.11mm 100nH
PDF
/
Inventory: 1386
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Q Factor 40
Quality Factor-Min (at L-nom) 40
Q @ Freq 40 @ 25MHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 400MHz
Max DC Current 500mA
DC Resistance (DCR) 60mOhm Max
Test Frequency 25MHz
Inductance 100nH
Lead Diameter 0.508 mm
Lead Length 25.4mm
Current Rating 500mA
Reach Compliance Code unknown
Construction Bobbin Core
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±20%
Size / Dimension 0.110Diax0.280L 2.79mmx7.11mm
Series 78F
Published 2005
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Ferrite
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
