9250-101
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
9250 Axial 0.162Diax0.410L 4.11mmx10.41mm 100nH
PDF
/
Inventory: 3946
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Q Factor 50
Quality Factor-Min (at L-nom) 50
Q @ Freq 50 @ 25MHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 250MHz
Max DC Current 1.79A
DC Resistance (DCR) 25mOhm Max
Test Frequency 25MHz
Inductance 100nH
Lead Diameter 0.635 mm
Lead Length 25.4mm
Current Rating 1.79A
Construction Flame Retardant Coat
Number of Functions 1
Shielding YES
Type Wirewound
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Tolerance ±10%
Size / Dimension 0.162Diax0.410L 4.11mmx10.41mm
Series 9250
Published 2005
Packaging Bulk
Operating Temperature -55°C~105°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Ferrite
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
