SPD73R-104M
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SPD73R Nonstandard 0.287Lx0.287W 7.30mmx7.30mm 100muH
PDF
/
Buying Options
Total Price: USD $3.47
Unit Price: USD $3.46779
≥1 USD $3.46779
≥10 USD $3.271504
≥100 USD $3.086324
≥500 USD $2.911625
≥1000 USD $2.746815
Inventory: 1549
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 0.154 3.90mm
Height 3.9mm
Technical
Case/Size Code 2929
Terminal Placement DUAL ENDED
Inductor Application POWER INDUCTOR
Max DC Current 850mA
DC Resistance (DCR) 790mOhm Max
Test Frequency 1kHz
Inductance 100μH
Current Rating 850mA
Construction Rectangular
Depth 7.8mm
Number of Functions 1
Shielding YES
Packing Method TR, 13 Inch
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Type Wirewound
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.287Lx0.287W 7.30mmx7.30mm
Series SPD73R
Published 2011
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape ONE SURFACE
Package / Case Nonstandard
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 18 Weeks
