SRU2016-101Y
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
SRU2016 Nonstandard 0.110Lx0.110W 2.80mmx2.80mm 100muH
PDF
/
Buying Options
Total Price: USD $0.68
Unit Price: USD $0.682252
≥1 USD $0.682252
≥10 USD $0.643632
≥100 USD $0.607203
≥500 USD $0.572832
≥1000 USD $0.540405
Inventory: 1090
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Terminal Shape ONE SURFACE
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2011
Series SRU2016
Size / Dimension 0.110Lx0.110W 2.80mmx2.80mm
Tolerance ±30%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination SMD/SMT
ECCN Code EAR99
Type Wirewound
Terminal Finish Tin (Sn)
Packing Method TR
Shielding YES
Number of Functions 1
Depth 3mm
Current Rating 190mA
Military Standard Not
Inductance 100μH
Test Frequency 100kHz
DC Resistance (DCR) 4.9Ohm Max
Current 1.5A
Max DC Current 190mA
Frequency - Self Resonant 10MHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL ENDED
Q @ Freq 8 @ 2.52MHz
Quality Factor-Min (at L-nom) 8
Current - Saturation 150mA
Q Factor 8
Case/Size Code 1111
DC Current 190mA
Dimensions
Height 1.65mm
Height Seated (Max) 0.071 1.80mm
Compliance
RoHS Status ROHS3 Compliant
