4922R-25L
RoHS
RoHS compliant
RoHS compliantPackage Nonstandard
Category Inductors, Coils, Chokes / Fixed Inductors
Description
4922R Nonstandard 0.505Lx0.240W 12.82mmx6.09mm 100muH
PDF
/
Buying Options
Total Price: USD $3.77
Unit Price: USD $3.7664
≥1 USD $3.7664
≥10 USD $3.15216
≥100 USD $2.877952
≥500 USD $2.466992
≥1000 USD $2.261336
≥3000 USD $2.192854
Inventory: 1252
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 45 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Nonstandard
Material - Core Ferrite
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2007
Series 4922R
Size / Dimension 0.505Lx0.240W 12.82mmx6.09mm
Tolerance ±15%
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Type Wirewound
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Composition Wirewound
Current Rating (Amps) 760mA
Shielding Unshielded
Depth 6.35mm
Current Rating 760mA
Inductance 100μH
Test Frequency 1kHz
DC Resistance (DCR) 672mOhm Max
Max DC Current 760mA
Inductance Frequency - Test 1kHz
Current - Saturation 760mA
Dimensions
Height 5.842mm
Height Seated (Max) 0.230 5.84mm
Length 12.827mm
Width 6.35mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
