1840-04G image
Favorite
1840-04G image
Favorite
RoHS
/
Package Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description Non-RoHS Compliant Molded Active WIRE Fixed Inductor -55C~125C 350MHz 50mOhm Max 330nH
PDF
/
Inventory: 9736
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 15 Weeks

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Axial
Terminal Shape WIRE
Material - Core Phenolic
Shape/Size Description TUBULAR PACKAGE

Technical

Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Published 2010
Series 1840
Size / Dimension 0.187Diax0.437L 4.75mmx11.10mm
Tolerance ±2%
JESD-609 Code e0
Pbfree Code no
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Number of Terminations 2
ECCN Code EAR99
Type Molded
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8504.50.80.00
Packing Method TR
Shielding NO
Number of Functions 1
Current Rating 2.36A
Reference Standard MS75008
Lead Length 36.58mm
Inductance 330nH
Test Frequency 25MHz
DC Resistance (DCR) 50mOhm Max
Max DC Current 2.36A
Frequency - Self Resonant 350MHz
Inductor Application RF INDUCTOR
Q @ Freq 55 @ 25MHz
Quality Factor-Min (at L-nom) 55
Q Factor 55

Dimensions

Diameter 4.75mm

Compliance

Radiation Hardening No
RoHS Status Non-RoHS Compliant
