1840R-04M
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Inductors, Coils, Chokes / Fixed Inductors
Description
ROHS3Compliant Molded Active WIRE Fixed Inductor -55C~125C 350MHz 50mOhm Max 330nH
PDF
/
Inventory: 5224
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Diameter 4.75mm
Technical
Q Factor 55
Quality Factor-Min (at L-nom) 55
Q @ Freq 55 @ 25MHz
Inductor Application RF INDUCTOR
Frequency - Self Resonant 350MHz
Max DC Current 2.36A
DC Resistance (DCR) 50mOhm Max
Test Frequency 25MHz
Inductance 330nH
Lead Length 36.58mm
Current Rating 2.36A
Number of Functions 1
Shielding NO
Packing Method TR, 14 INCH
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Type Molded
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance ±20%
Size / Dimension 0.187Diax0.437L 4.75mmx11.10mm
Series 1840R
Published 2010
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Shape/Size Description TUBULAR PACKAGE
Material - Core Phenolic
Terminal Shape WIRE
Package / Case Axial
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 15 Weeks
