PIC16LF1615T-I/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 8BIT 14KB FLASH 14SOIC
PDF
/
Inventory: 8891
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2014
Series PIC? XLP? 16F
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 14
Subcategory Microcontrollers
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 3V
Terminal Pitch 1.27mm
Base Part Number PIC16LF1615
JESD-30 Code R-PDSO-G14
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 2/3.3V
Supply Voltage-Min (Vsup) 1.8V
Oscillator Type Internal
Number of I/O 12
Speed 32MHz
RAM Size 1K x 8
Voltage - Supply (Vcc/Vdd) 1.8V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor PIC
Peripherals Brown-out Detect/Reset, POR, PWM, WDT
Clock Frequency 32MHz
Program Memory Type FLASH
Core Size 8-Bit
Program Memory Size 14KB 8K x 14
Connectivity I2C, LINbus, SPI, UART/USART
Supply Current-Max 6mA
Bit Size 8
Data Converter A/D 8x10b; D/A 1x8b
Has ADC YES
DMA Channels NO
PWM Channels YES
DAC Channels YES
ROM (words) 8192
On Chip Program ROM Width 14
Boundary Scan NO
Low Power Mode NO
Format FIXED-POINT
Integrated Cache NO
RAM (words) 1024
Number of Serial I/Os 1
Number of Timers 8
Number of External Interrupts 1
On Chip Data RAM Width 8
Dimensions
Height Seated (Max) 1.75mm
Length 8.65mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
