PCM1681PWPG4
RoHS
/
Package HTSSOP EP
Category Integrated Circuits (ICs) / Linear - Amplifiers - Audio
Description
e4 HTSSOP EP I2C SPI Serial Voltage audio amplifier 5.5V 9.7mm 386mW 3B
PDF
/
Inventory: 1521
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 4.4mm
Length 9.7mm
Height Seated (Max) 1.2mm
Technical
Number of DAC Channels 8
Number of ADC Channels 0
Signal to Noise Ratio (SNR) 105 dB
Conversion Rate 192 ksps
Input Bit Code 2'S COMPLEMENT BINARY
Power Consumption 386mW
Sampling Rate 192 ksps
Resolution 3 B
Supply Type Analog, Digital
Converter Type D/A CONVERTER
Number of Bits 24
Power Dissipation-Max 466mW
Min Supply Voltage 4.5V
Max Supply Voltage 5.5V
Interface I2C, SPI, Serial
Temperature Grade INDUSTRIAL
Operating Supply Voltage 5V
Output Type Voltage
Pin Count 28
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Subcategory Other Converters
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3
JESD-609 Code e4
Physical
Weight 118.501007mg
Number of Pins 28
Package / Case HTSSOP EP
Mount Surface Mount
