ATSAM3S1CB-CUR
RoHS
RoHS compliant
RoHS compliantPackage 100-TFBGA
Category Integrated Circuits (ICs) / Embedded - Microcontrollers
Description
IC MCU 32BIT 64KB FLASH 100TFBGA
PDF
/
Inventory: 9173
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mounting Type Surface Mount
Package / Case 100-TFBGA
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Cut Tape (CT)
Published 1997
Series SAM3S
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 100
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Supply Voltage 1.8V
Terminal Pitch 0.8mm
Base Part Number ATSAM3S1
JESD-30 Code S-PBGA-B100
Supply Voltage-Max (Vsup) 1.95V
Supply Voltage-Min (Vsup) 1.62V
Oscillator Type Internal
Number of I/O 79
Speed 64MHz
RAM Size 16K x 8
Voltage - Supply (Vcc/Vdd) 1.62V~3.6V
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC
Core Processor ARM? Cortex?-M3
Peripherals Brown-out Detect/Reset, DMA, I2S, POR, PWM, WDT
Clock Frequency 20MHz
Program Memory Type FLASH
Core Size 32-Bit
Program Memory Size 64KB 64K x 8
Connectivity EBI/EMI, I2C, Memory Card, SPI, SSC, UART/USART, USB
Bit Size 32
Data Converter A/D 15x10/12b; D/A 2x12b
Has ADC YES
DMA Channels YES
PWM Channels YES
DAC Channels YES
Address Bus Width 24
On Chip Program ROM Width 8
Screening Level TS 16949
External Data Bus Width 8
Dimensions
Height Seated (Max) 1.1mm
Length 9mm
Width 9mm
Compliance
RoHS Status ROHS3 Compliant
