TL750L05QDR
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Voltage Regulators - Linear
Description
Contains Lead GULL WING Not Qualified BIPOLAR voltage regulator linear 125C 0.15A 4.9mm 5.25V
PDF
/
Buying Options
Total Price: USD $0.77
Unit Price: USD $0.766824
≥1 USD $0.766824
≥10 USD $0.723426
≥100 USD $0.682472
≥500 USD $0.643843
≥1000 USD $0.607404
Inventory: 1148
Minimum: 1
-
+
Technical Details
Physical
Package / Case SOIC
Surface Mount YES
Technical
Pbfree Code no
Number of Terminations 8
ECCN Code EAR99
HTS Code 8542.39.00.01
Subcategory Other Regulators
Packing Method TAPE AND REEL
Technology BIPOLAR
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
JESD-30 Code R-PDSO-G8
Number of Outputs 1
Qualification Status Not Qualified
Quiescent Current 1mA
Output Voltage 1 5V
Input Voltage (Min) 6V
Input Voltage (Max) 26V
Dropout Voltage 600mV
Dropout Voltage1-Nom 0.6V
Output Voltage1-Max 5.25V
Output Voltage1-Min 4.75V
Regulator Type FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR
Voltage Tolerance-Max 5%
Output Current1-Max 0.15A
Operating Temperature TJ-Max 125°C
Input Voltage Absolute-Max 26V
Adjustability FIXED
Load Regulation-Max(%) 0.05%
Line Regulation-Max (%/V) 0.03%
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
