STTH3010WY
RoHS
RoHS compliant
RoHS compliantPackage DO-247-2 (Straight Leads)
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
Diode Switching 1KV 30A 2-Pin DO-247 Tube
PDF
/
Buying Options
Total Price: USD $22.12
Unit Price: USD $22.1198
≥1 USD $22.1198
≥10 USD $18.14975
≥100 USD $17.5826
≥500 USD $17.01545
≥1000 USD $16.4483
Inventory: 1155
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Recovery Time 42 ns
Peak Non-Repetitive Surge Current 180A
Reverse Recovery Time 100 ns
Number of Phases 1
Average Rectified Current 30A
Max Reverse Voltage (DC) 1kV
Forward Voltage 2V
Voltage - DC Reverse (Vr) (Max) 1000V
Application HIGH VOLTAGE ULTRA FAST SOFT RECOVERY
Operating Temperature - Junction -40°C~175°C
Max Reverse Leakage Current 100μA
Voltage - Forward (Vf) (Max) @ If 2V @ 30A
Current - Reverse Leakage @ Vr 15μA @ 1000V
Diode Type Standard
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Single
Number of Elements 1
Base Part Number STTH30
Subcategory Rectifier Diodes
Additional Feature LOW LEAKAGE CURRENT
Min Operating Temperature -40°C
Max Operating Temperature 175°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series Automotive, AEC-Q101
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 2
Package / Case DO-247-2 (Straight Leads)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 months ago)
Factory Lead Time 11 Weeks
