JCD0605S12

XP Power
RoHS
RoHS RoHS compliant
Package 24-DIP Module, 7 Leads
Category Power Supplies - Board Mount / DC DC Converters
Description XP POWER JCD0605S12 Isolated Board Mount DC/DC Converter, 2:1 Input, Fixed, 1 Output, 4.5 V, 9 V, 6 W, 12 V
PDF
/
Buying Options
Total Price: USD $23.32
Unit Price: USD $23.32
≥1 USD $23.32
≥10 USD $22
≥100 USD $20.75472
≥1000 USD $18.47162
Inventory: 2061
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
REACH SVHC Unknown

Dimensions

Width 20.32mm
Height 10.4mm

Technical

Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 9V
Nominal Output Voltage 12V
Max Output Power 6W
Current - Output 1 500mA
Output Power 6W
Output Current 500mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Max Output Current 500mA
Output Voltage 12V
Voltage - Input (Max) 9V
Voltage - Isolation 1.6kV
Efficiency 83%
Number of Outputs 1
JESD-30 Code R-XDMA-P8
Pin Count 24/8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Depth 31.75mm
Terminal Pitch 2.54mm
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form PIN/PEG
Terminal Position DUAL
Technology HYBRID
Max Power Dissipation 6W
Power Rating 6W
Applications ITE (Commercial)
Type Isolated Module
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature OCP, OVP, SCP
Size / Dimension 1.25Lx0.80W x 0.41 H 31.8mmx20.3mmx10.4mm
Series JCD (6W)
Published 2013
Packaging Tube
Operating Temperature -40°C~100°C

Physical

Package / Case 24-DIP Module, 7 Leads
Mounting Type Through Hole
Mount PCB, Through Hole

Supply Chain

Factory Lead Time 10 Weeks
