PB01S0509A
RoHS
RoHS compliant
RoHS compliantPackage 5-SIP Module
Category Power Supplies - Board Mount / DC DC Converters
Description
Module DC-DC 1-OUT 9V 0.11A 1W 4-Pin SIP
PDF
/
Buying Options
Total Price: USD $5.68
Unit Price: USD $5.68115
≥1 USD $5.68115
≥10 USD $5.35957
≥100 USD $5.0562
≥500 USD $4.77
≥1000 USD $4.5
Inventory: 5245
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Height 10.16mm
Technical
Min Input Voltage (DC) 4.5V
Max Input Voltage (DC) 5.5V
Total Power Output-Max 1W
Current - Output 1 110mA
Output Power 1W
Output Current 110mA
Trim/Adjustable Output NO
Input Voltage-Nom 5V
Voltage - Input (Min) 4.5V
Max Output Current 110mA
Output Voltage 9V
Voltage - Isolation 1kV
Efficiency 76%
Number of Outputs 1
JESD-30 Code R-PSMA-T5
Terminal Pitch 2.54mm
Number of Functions 1
Terminal Position SINGLE
Technology HYBRID
Max Power Dissipation 1W
Applications Medical
Type Isolated Module
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature SCP
Size / Dimension 0.77Lx0.24W x 0.40 H 19.6mmx6.0mmx10.2mm
Series PB01S/D (1W)
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Package / Case 5-SIP Module
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 9 Weeks
