108LBB100M2CC
RoHS
RoHS compliant
RoHS compliantPackage Radial, Can - Snap-In
Category Capacitors / Aluminum Electrolytic Capacitors
Description
Radial Can - Snap-In ALUMINUM ELECTROLYTIC CAPACITOR LBB 100V 1000muF ±20% 0.984Dia 25.00mm
PDF
/
Inventory: 2895
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mount PCB, Through Hole
Mounting Type Through Hole
Package / Case Radial, Can - Snap-In
Dielectric Material ALUMINUM (WET)
Technical
Operating Temperature -40°C~85°C
Packaging Bulk
Published 2002
Series LBB
Size / Dimension 0.984Dia 25.00mm
Tolerance ±20%
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Termination Snap in
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Applications General Purpose
Capacitance 1000μF
Voltage - Rated DC 100V
Lead Pitch 10.0076mm
Capacitor Type ALUMINUM ELECTROLYTIC CAPACITOR
ESR (Equivalent Series Resistance) 248.68mOhm @ 120Hz
Lead Spacing 0.394 10.00mm
Lifetime @ Temp 3000 Hrs @ 85°C
Leakage Current 3mA
Ripple Current 2A
Polarization Polar
Life (Hours) 3000 hours
Ripple Current @ Low Frequency 2A @ 120Hz
Ripple Current @ High Frequency 2.5A @ 10kHz
Dissipation Factor 0.15 %
Dimensions
Diameter 1mm
Height Seated (Max) 1.063 27.00mm
Compliance
RoHS Status ROHS3 Compliant
