ERZ-E08A361CS
RoHS
RoHS compliant
RoHS compliantPackage Disc 10.5mm
Category Circuit Protection / TVS - Varistors, MOVs
Description
VARISTOR 360V 3.5KA DISC 10.5MM
PDF
/
Inventory: 1954
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 6.1mm
Diameter 10.5mm
Technical
Clamping Current 25A
Current - Surge 3.5kA
Maximum DC Volts 300V
Varistor Voltage 324V
Maximum AC Volts 230V
Varistor Voltage (Typ) 360V
Varistor Voltage (Min) 324V
Energy 65J
Varistor Voltage (Max) 396V
Capacitance @ Frequency 280pF @ 1kHz
Max Surge Current 3.5kA
Clamping Voltage 595V
Max Voltage Rating (DC) 300V
Max Voltage Rating (AC) 230V
Number of Circuits 1
Lead Pitch 7.5mm
Voltage - Rated AC 230V
Voltage - Rated DC 300V
Capacitance 280pF
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ZNR?
Packaging Bulk
Operating Temperature -40°C~85°C TA
Physical
Package / Case Disc 10.5mm
Mounting Type Through Hole
Mount Radial, Through Hole
Supply Chain
Factory Lead Time 10 Weeks
