CG0603MLC-24LE
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Circuit Protection / TVS - Varistors, MOVs
Description
ESD Suppressor ±25KV 2-Pin Case 0603 T/R
PDF
/
Buying Options
Total Price: USD $0.33
Unit Price: USD $0.3256
≥1 USD $0.3256
≥10 USD $0.26312
≥100 USD $0.240768
≥500 USD $0.179168
≥1000 USD $0.162378
≥3000 USD $0.134394
Inventory: 1139
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length 1.6mm
Technical
Maximum DC Volts 24V
Capacitance @ Frequency 0.5pF @ 1MHz
Clamping Voltage 25V
Max Voltage Rating (DC) 24V
Element Configuration Single
Number of Circuits 1
Leakage Current 5nA
Working Voltage 24V
Case Code (Imperial) 0603
Case Code (Metric) 1608
Base Part Number CG060
Depth 800μm
Capacitance 500FF
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series ChipGuard? MLC
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 2
Package / Case 0603 (1608 Metric)
Mounting Type Surface Mount, MLCV
Mount Surface Mount
Supply Chain
Factory Lead Time 9 Weeks
