CG0603MLC-12LEA
RoHS
RoHS compliant
RoHS compliantPackage 0603 (1608 Metric)
Category Circuit Protection / TVS - Varistors, MOVs
Description
VARISTOR 0603
PDF
/
Buying Options
Total Price: USD $0.43
Unit Price: USD $0.4312
≥1 USD $0.4312
≥10 USD $0.35112
≥100 USD $0.321024
≥500 USD $0.23892
≥1000 USD $0.216515
≥3000 USD $0.179186
Inventory: 4784
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount, MLCV
Package / Case 0603 (1608 Metric)
Number of Pins 2
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
Published 2012
Series ChipGuard? MLC
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Capacitance 500FF
Voltage - Rated DC 12V
Depth 800μm
Current Rating 5nA
Base Part Number CG060
Case Code (Metric) 1608
Case Code (Imperial) 0603
Operating Supply Voltage 12V
Working Voltage 12V
Number of Channels 1
Voltage 12V
Leakage Current 5nA
Number of Circuits 1
Element Configuration Single
Max Voltage Rating (DC) 12V
Clamping Voltage 25V
Capacitance @ Frequency 0.5pF @ 1MHz
Maximum DC Volts 12V
Dimensions
Length 1.6mm
Width 800μm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
