NP1500SAMCT3G
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
THYRISTOR 140V 150A DO214AA
PDF
/
Inventory: 7803
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2010
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
Capacitance 23pF
Terminal Position DUAL
Terminal Form C BEND
Pin Count 2
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 50A
Peak Pulse Current 150A
Max Repetitive Reverse Voltage (Vrrm) 140V
Hold Current 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Breakover 180V
Voltage - On State 4V
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
