P2600Q22CLRP
RoHS
RoHS compliant
RoHS compliantPackage 2-TDFN
Category Circuit Protection / TVS - Thyristors
Description
SIDACTOR BI 300V 400A QFN SMD
PDF
/
Buying Options
Total Price: USD $0.74
Unit Price: USD $0.73785
≥1 USD $0.73785
≥200 USD $0.286212
≥500 USD $0.275709
≥1000 USD $0.270457
Inventory: 8042
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 22 Weeks
Physical
Mounting Type Surface Mount
Package / Case 2-TDFN
Surface Mount YES
Number of Pins 2
Technical
Packaging Tape & Reel (TR)
Published 2007
Series SIDACtor?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Additional Feature UL RECOGNIZED
Capacitance 45pF
Subcategory Silicon Surge Protectors
Terminal Position BOTTOM
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 100A
Peak Pulse Current 400A
Hold Current 150mA
Voltage - Off State 220V
Non-Repetitive Pk On-state Cur 30 A
Voltage - Breakover 300V
Voltage - On State 5V
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
