P1800SARP
RoHS
/
Package DO-214AA, SMB
Category Circuit Protection / TVS - Thyristors
Description
SIDACTOR BIDIR 170V 150A DO-214
PDF
/
Inventory: 9413
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case DO-214AA, SMB
Surface Mount YES
Technical
Packaging Tape & Reel (TR)
Published 2004
Series SIDACtor?
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Capacitance 35pF
Subcategory Silicon Surge Protectors
Voltage - Rated DC 170V
Terminal Position DUAL
Terminal Form C BEND
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Current Rating 2.2A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
JESD-30 Code R-PDSO-C2
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 45A
Peak Pulse Current 150A
Hold Current 150mA
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 170V
Non-Repetitive Pk On-state Cur 20 A
Voltage - Breakover 220V
Voltage - On State 4V
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
