P1300EA
RoHS
/
Package TO-226-2, TO-92-2 (TO-226AC)
Category Circuit Protection / TVS - Thyristors
Description
SIDACTOR SURGE SUP TO92 120V
PDF
/
Buying Options
Total Price: USD $5.25
Unit Price: USD $5.24875
≥1 USD $5.24875
≥10 USD $4.30635
≥100 USD $4.1724
≥500 USD $4.0375
≥1000 USD $3.9026
Inventory: 1524
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-2, TO-92-2 (TO-226AC)
Surface Mount NO
Technical
Packaging Bulk
Published 2011
Series SIDACtor?
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
Terminal Finish Tin/Lead (Sn/Pb)
Capacitance 45pF
Subcategory Silicon Surge Protectors
Terminal Position BOTTOM
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code O-PBCY-T2
Qualification Status Not Qualified
Operating Temperature (Min) -40°C
Number of Elements 1
Configuration SINGLE
Current - Peak Pulse (10/1000μs) 45A
Trigger Device Type SILICON SURGE PROTECTOR
Voltage - Off State 120V
Non-Repetitive Pk On-state Cur 20 A
Current - Hold (Ih) 150mA
Voltage - Breakover 160V
Voltage - On State 4V
Current - Peak Pulse (8/20μs) 150A
Compliance
RoHS Status Non-RoHS Compliant
