RKEF090
RoHS
RoHS compliant
RoHS compliantPackage Radial, Disc
Category Circuit Protection / PTC Resettable Fuses
Description
PTC RESET FUSE 60V 900MA RADIAL
PDF
/
Buying Options
Total Price: USD $0.47
Unit Price: USD $0.4664
≥1 USD $0.4664
≥10 USD $0.45056
≥100 USD $0.43648
≥500 USD $0.367136
≥1000 USD $0.304744
≥3000 USD $0.277094
Inventory: 745
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mounting Type Through Hole
Package / Case Radial, Disc
Technical
Operating Temperature -40°C~85°C
Packaging Bag
Published 2013
Series PolySwitch?, RKEF
Size / Dimension 0.310Lx0.140W 7.87mmx3.56mm
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Polymeric
Reach Compliance Code unknown
Approval Agency CSA, TUV, UL
Lead Spacing 0.200 5.08mm
Current - Max 40A
Current - Hold (Ih) (Max) 900mA
Voltage - Max 60V
Time to Trip 2s
Resistance - Initial (Ri) (Min) 190mOhm
Resistance - Post Trip (R1) (Max) 520mOhm
Current - Trip (It) 1.8A
Dimensions
Height Seated (Max) 0.550 13.97mm
Compliance
RoHS Status ROHS3 Compliant
